KXTF9 Series
Accelerometers and Inclinometers
Digital I C 8-bit or 12-bit Resolution
FEATURES
Ultra-Small Package - 3x3x0.9mm LGA
User-selectable G Range
User-selectable Output Data Rate
Directional Tap/Double-Tap TM Detection Algorithm
Active/Inactive Detection Algorithm
Device-orientation Detection Algorithm
2
Digital High-Pass Filter Outputs
Low Power Consumption
Lead-free Solderability
Excellent Temperature Performance
High Shock Survivability
Factory Programmable Offset and Sensitivity
Self-test Function
PROPRIETARY TECHNOLOGY
MARKETS
APPLICATIONS
Mobile Phones and Mobile Internet Devices
User Interface
Gesture Recognition
Power Management
Active/Inactive Monitoring
Game Controllers and Computer Peripherals
Inclination and Tilt Sensing
User Interface
Power Management
Activity Monitoring
Gesture Recognition
Health Care and Fitness
Static and Dynamic Acceleration
Activity Monitoring
Gesture Recognition
Personal Navigation Devices
E-Compass
Dead Reckoning
These high-performance silicon micromachined linear accelerometers and incli-
nometers consist of a sensor element and an ASIC packaged in a 3x3x0.9mm
Land Grid Array (LGA). The sensor element is fabricated from single-crystal
silicon with proprietary Deep Reactive Ion Etching (DRIE) processes, and is
protected from the environment by a hermetically-sealed silicon cap at the
wafer level.
The KXTF9’s Directional Tap/Double-Tap TM detection feature recognizes single-
tap and double-tap input and reports the acceleration axis and direction from
which each tap originated, enabling up to 12, user-defined, function com-
mands. Its active/inactive algorithm reports changes in a device’s motion
state, either moving (active) or not moving (inactive), and the orientation-
detection feature reports changes in landscape, portrait, face-up, and face-
down conditions. A highly-manufacturable product with consistent product
performance across use conditions, the KXTF9 operates across a supply volt-
age of 1.8V to 3.6V DC.
The sensor element functions on the principle of differential capacitance. Ac-
celeration causes displacement of a silicon structure resulting in a change in
capacitance. The sense element design utilizes common mode cancellation to
decrease errors from process variation and environmental stress.
An ASIC,
using a standard CMOS manufacturing process, detects and transforms capaci-
tance changes into an analog voltage, which is proportional to acceleration.
Analog signals are further processed into digital signals and within embedded
digital algorithms. The device communicates to the system via I 2 C bus inter-
face.
36 Thornwood Dr. - Ithaca, NY 14850 USA tel: 607-257-1080 - fax: 607-257-1146 - www.kionix.com - info@kionix.com
“ Kionix” is a registered trademark of Kionix, Inc. Products described herein are protected by patents issued or pending. Information provided
in this document is believed to be accurate and reliable but is not guaranteed. Kionix does not assume responsibility for its use or distribution.
No license is granted by implication or otherwise under any patent or other rights of Kionix. Kionix reserves the right to change product
specifications or discontinue this product at any time without prior notice.
? Kionix 2011 All Rights Reserved
March 22, 2011 Rev. 3
Page 1 of 2
